    3-axis fixed-point cabinet type carbon dioxide laser marking machine

    Ask Lasest Price
    Brand Name : DH
    Model Number : DH3040
    Certification : CE/ISO9001
    Payment Terms : T/T, Western Union
    • Product Details
    • Company Profile

    3-axis fixed-point cabinet type carbon dioxide laser marking machine

    Fixed-Point Laser Machine


    Describe


    3-axis fixed-point cabinet type carbon dioxide laser marking machine
    Clear effect, simple operation, and the ability to process various non-metallic materials such as leather, plastic, and glass. Compared with traditional mechanical processing methods, laser engraving has the advantages of non-contact, pollution-free, fast speed, and high accuracy. It is one of the advanced laser marking equipment.


    Features


    Applicable materials: non-metallic materials, bamboo and wood products, acrylic, PVC, leather, paper products, rubber products, silicone and other materials
    Wide application: Donghui 3040 laser machine is widely used for marking and cutting graphics and text in clothing accessories, leather bag decorations, food and beverage packaging, wood furniture, electronic components, handicraft processing, electrical equipment, glass and stone processing and other fields.


    Spefication


    Technical Parameters

    Laser parameters


    Laser output power40W/60W (optional)
    lasercarbon dioxide laser
    Laser wavelength1064nm
    Beam quality㎡≤1.2
    Pulse frequency0-25KHz
    Exit beam diameter1.8±0.2mm
    Output power stability±5%

    Optical properties


    Marking range110-300mm optional
    Print depth0.01-0.6mm (depending on power and material)
    Marking speed≤10000mm/s
    Repeat accuracy±0.001mm
    Minimum line width0.015mm
    Minimum characters0.15mm

    Usage environment


    cooling method40w air cooling/60w water cooling
    Maximum power consumption≤550W
    Input power240V/50Hz (can be connected to 110V)
    temperature humidity5-40℃, 30%≤RH≤85%, non-condensing

    Other parameters


    operating systemWindows operating system
    file formatAll fonts/fonts in the Windows operating system font library (standard USB input)
    Dimensions80*78*145cm
    equipment weightAbout 80kg

    Printing effect


    3-axis fixed-point cabinet type carbon dioxide laser marking machine3-axis fixed-point cabinet type carbon dioxide laser marking machine
